• MPEG-4 and JPEG multi format

• Up to 64 network cameras can be connected without extra license fee and their images can be recorded simultaneously.

• 200 Mbps high throughput: Best match with Megapixel i-Pro Network Cameras

• Various Recording Modes: Manual, Schedule including Event (Pre/Post), Emergency. Schedule mode includes eight recording programs with individual recording mode for each camera, and 6 time schedules per day.

• Panasonic camera control: Pan/Tilt, Zoom, Focus, Brightness, Preset Position, Auto mode (depending on camera model).

• Audio from i-Pro network cameras can be recorded and played back, G.726 (ADPCM) 32 kbps.

• Cameras can be assigned to one of the 8 groups for easier browsing.

• Flexible playback controls: Goto Date (Jump to specific time/date), Goto Last (Jump to 5 sec. ~ 5 min. before the record end).

• Various display modes: Spot, Quad (16 patterns), Spot Sequence, Quad Sequence (Live).

• Filtered search: Time & Date, Event Type, Camera number.

• VMD search: Motion in a specified area in the recorded images can quickly be searched (works with supported i-Pro cameras and WJ-NT314).

• 2x, 4x Digital zoom (Live/Playback)

• Recorded images can be downloaded to a PC. Downloadable viewer software allows playback of images downloaded from the recorder.

• Various alarm sources include 32x Terminal inputs, 64x Camera alarms, Panasonic Alarm Protocol. Flexible alarm actions include Event recording, E-mail notification, Alarm message, Camera positioning, FTP image transfer, Terminal output, Panasonic alarm protocol output, Buzzer and LED.

• 2x built-in network interfaces (10Base-T / 100Base-TX / 1000Base-T) for camera recording and client access

• Up to 16 clients can monitor images and control WJ-ND400 simultaneously.

• FTP client function enables periodic live image transfer or recorded image transfer in response to an alarm.

• Performance measurement function for appropriate recording frame rate setup

• Images recorded in the SD memory card in i-Pro network cameras can be transferred to the recorder automatically even when the recorder is in recording status.

• Setup can be made with the user friendly browser GUI. Multilingual options include English / French / Spanish / Germany / Italian / Russian / Chinese / Japanese.

• User/Host authentication, 4 programmable user levels, 16 user priorities and User-Camera View/Control partitioning set up for sophisticated user management. Up to 32 user registrations

• Alteration detection and recorded data encryption for data security

• Multi-recorder-Multi-site-system can be made with optional WVASM100 i-Pro Management Software.

• Up to 9 Serial ATA HDDs can be installed. With hot plug support, the HDDs can be removed without interrupting the recording.

• HDD capacity is expandable up to 54 HDD slots (9 HDD slots in the main unit and 5 optional WJ-HDE400 Hard Disk Extension Units each with 9 HDD slots).

• Disk partitioning including Normal, Event, Pre-Event, Copy for flexible record management

• RAID5/6 redundant recording for data security

• Superior reliability with an embedded OS compared to PC-based system
